With this in mind, what are the key UK revenue streams for generators considering energy storage?
System frequency is determined and controlled by the real time balance between system demand and total generation. The frequency falls if demand is greater than generation. If generation is greater than demand, the frequency rises. National Grid has a licence obligation to control frequency. The limits specified in the 'Electricity Safety, Quality and Continuity Regulations 2002', are ±1% nominal system frequency (50.00Hz), save in abnormal or exceptional circumstances. This requires National Grid to ensure that sufficient generation and / or demand is available to manage frequency variations.1
Firm Frequency Response (FFR)
FFR is designed to complement other types of Frequency Response and delivers firm availability. The service can be either dynamic – energy changes in line with system frequency – or static – energy change occurs at present frequency and remains at a set level.2 The tendered service of FFR is open to Balancing Mechanism Units (BMU), being the units of trade within the Balancing Mechanism used to balance supply and demand in each half hour trading period of every day, and to Non-BMU providers, thereby increasing the number of potential response providers and improving liquidity. FFR also creates a route to market for providers whose services may otherwise be inaccessible. The minimum power capacity to provide the FFR service is 10 MW. This may be from a single unit or aggregated from several smaller units. Units of less than 10 MW but planning to reach this threshold in the near future may be able to participate through a separate route.3
Suppliers can provide a Primary, Secondary or High Frequency Response if the frequency moves outside a deadband (±0.015 Hz) or past a pre-agreed level:
- Primary Response: provide additional active power or decrease demand within 10 seconds and sustain for a further 20 seconds.
- Secondary Response: provide additional active power or demand reduction within 30 seconds and sustain for a further 30 minutes.
- High Frequency Response: provide a reduction in active power or increase in demand within 10 seconds and sustain this indefinitely.4
Tenderers may provide a combined Primary and Secondary static service. National Grid’s priority is for secondary response. National Grid procures the services through a competitive tender process, where tenderers can bid for low frequency events, high frequency events or both.5 National Grid will accept the most economical tenders. A successful tender then becomes contractually binding. The tenor of each bid varies, as tenderers are required to specify a “Tendered Service Period” when submitting their application.
Renewable energy generators with storage are able to participate in FFR, but must demonstrate a high level of availability of the service, typically requiring a permanent increase in grid import and export capacity for wind farms, or tendering only during hours of low generation for more predictable generators such as solar farms. National Grid nominates the hours of delivery to be tendered for 1 month in advance. The availability and nomination price is then set at a standard £/h rate for the duration.
Following a period of review in early 2016, National Grid has introduced a suite of complementary services to sit alongside the existing framework, which aim to increase flexibility and efficiency. Providers may now tender 1 month in advance, but nominate their MW a week ahead, on a settlement period basis. The associated price would therefore be on a £/MW/h basis. An associated pricing-related relief is the introduction of spread index tenders. his will replace the current fixed availability and nomination fee regime with spread indexed contracts, which will remove market risk by guaranteeing profitability at the nominated part load point. In relation to penalties, providers will now be able to (i) temporarily reduce their MW output without incurring a penalty; and (ii) avoid penalties backdated any further than 1 year from the event of default. In the interests of transparency, the company name and fuel type associated with each tenderer will be published to improve market efficiency. Finally, new, sub-sites will be able to be added more easily by providers to their existing frameworks without the need for any additional approvals or arduous documentation.6
Enhanced Frequency Response (EFR)
EFR is a service that achieves 100% active power output at 1 second (or less) of registering a frequency deviation. This is in contrast with Primary and High Frequency FFR services which have response times of 10 seconds, and Secondary FFR which has a response time of 30 seconds. This is a new service that is being developed to improve management of the system frequency pre-fault, i.e. to maintain the system frequency closer to 50 Hz under normal operation.
In July 2016, National Grid procured 200 MW of EFR. Contracts were awarded subject to a 50 MW cap per pre-qualified party. Tenderers had to deliver an EFR service capable of operating at maximum charge or discharge for a continuous period of 30 minutes. The terms restricted committed EFR assets from concurrently providing a dual service, but EFR storage facilities were allowed to provide different services within a 24 hour period if not contracted to EFR at the specified times of the tender. The ability to provide dual service was also subject to prior approval by National Grid. Successful tenders underwent a two stage evaluation. Stage one required tenders to comply with the required application format. Stage two evaluated the tenders based on the total cost to National Grid rather than the unit price offered through the tender. Proposals were compared against the forecast cost of alternative action for the specified usage period of the provision of EFR.
The results of this process were published on 26 August 2016 with an average price of £9.44/MW per EFR/hour, as follows:
|Bidder||Capacity procured (MW)||Price (£/MW of EFR/hour)|
|EDF Energy Renewables
Winning bids were at the lower end of expectations, suggesting that some bidders placed artificially low bids to gain first mover advantage or made more optimistic estimates of future revenue streams. National Grid offered 4 year contracts for EFR, which whilst less than the expected payback time of a storage system, provides greater certainty than for FFR.
The majority of the EFR capacity was won by storage providers, who benefited greatly from the objective of the tender, which despite being technology neutral, had at its heart decarbonisation of the traditional technical capacity fleet. The Renewable Energy Association’s head of policy and external affairs, James Court, highlighted the significance of this result, as the UK storage industry is now starting to deliver on its promise to become a world leader.
Renewable energy generators with storage are able to participate in EFR, but must demonstrate a high level of availability of the service, typically requiring a permanent increase in grid import and export capacity for wind farms, or tendering only during hours of low generation for more predictable generators such as solar farms.
The capacity market in the UK has been established to provide certain, regular payments to capacity providers, in return for which they must be available and producing electricity (or reducing demand) in times of system stress.
The capacity market could theoretically include electricity storage projects. The use of battery storage with a renewable energy source creates dispatchable generation allowing such systems which are of a suitable capacity and power output to participate in the capacity market. Energy storage must be of sufficient capacity to allow sustained power generation at the agreed level.
Successful tenderers are offered capacity agreements for different terms depending on whether plants are new or have been refurbished. To date the price set per kilowatt has been too low to justify capital investment in new energy storage projects. This has made it easier for existing nuclear and fossil fuel generators to offer ‘spare’ capacity into the auction at a much lower marginal cost. However, the capacity market may be considered as part of the business case for an energy storage project, as a follow-on revenue stream after contracts for more lucrative but short term ancillary services have expired.
Recent changes to the capacity market include lowering the minimum size of load reduction demand side response units to 500 kW, which should enable more storage projects to participate in the mechanism. Stronger penalties for not delivering capacity are also likely to help the mechanism’s attractiveness for storage projects. The mechanism continues to be criticised for supporting higher-carbon electricity generation.
Penalties are payable for failing to provide capacity. Providers with renewable sources and battery storage may consider not participating, as the potential open ended generating requirement may restrict them from delivering other ancillary services with higher revenue potential and means that tenderers must account for the cost of imported electricity to avoid the risk of financial penalties for not meeting their required output level.
Short Term Operating Reserve (STOR)
STOR capacity is retained on stand-by,to be called on to generate within four hours of instruction. The need can arise from demand forecast errors, unexpected loss of thermal generation and variable wind generation. Availability payments are made during contracted windows and utilisation payments are made whenever reserve is delivered. STOR is open to transmission connected generation from large power station sites and small transmission or distribution connected generation and demand. National Grid procures STOR through a tender process. STOR projects are required to fulfil a number of criteria, including an ability to deliver at least 3 MW of reserve, an ability to react within 240 minutes of an instruction, an ability to deliver for a minimum of two hours, have a recovery period after provision of reserve of less than 20 hours, be able to provide reserve at least three times a week (though average utilisation will be much lower) and operational metering.
Renewable sources with energy storage can participate in this service, as storage permits dispatchable output for a period of time. It is possible to participate in this service individually or through an aggregator for smaller generators. While participation in this service should be considered, availability prices are significantly lower than for frequency response services.
Fast Reserve is a balancing service where the service provider delivers a contracted power output within agreed limits, when instructed to by National Grid. This is similar to the STOR service, but has a shorter timescale, with a much greater response rate of 25 MW/minute at a minimum. Fast Reserve provides rapid and reliable delivery of active power through an increased output from generation or a reduction in consumption from demand sources, following receipt of an electronic despatch instruction from National Grid. This service operates in quicker timeframes than STOR and requires a 50 MW minimum capacity. As such, it will only be suitable for larger projects or through an aggregator service.
To participate in this service a renewable source and battery storage system with sufficient large storage capacity and power output would be required. The power output from a battery energy storage system can be rapidly adjusted, far exceeding the ramp rate requirements. While participation in this service is possible using battery storage, the provider would likely be paid more for participating in services that more fully utilise the unique capabilities and very short response times of battery storage.
Generators who export during the three peak consumption periods may be eligible for Triad payments. National Grid selects three half hour periods of peak demand during the triad period. The triad period occurs between the months of November and February inclusive each year and each triad period is a minimum of ten days apart. The average of the maximum demand for customers over the three triad periods is used to calculate their Transmission Grid Use of System (TNUoS) charge for energy suppliers for the year, which they then pass onto their customers. Embedded generators within a Distribution Network Operator’s (DNO) grid can benefit by exporting energy during triad periods.
Renewable energy generators are well placed to install energy storage to improve the benefit from Triad payments as long as there is a pass through mechanism in the power purchase agreement pursuant to which generators sell electricity to electricity suppliers. Triad payments, along with other embedded benefits, are currently under review by Ofgem and are likely to change due to the increased proportion of embedded generation. It is unclear whether this benefit will continue to be available in its current form.
Super Red Credits
Super Red Credits are payments provided by DNOs to non-intermittent generators for exporting energy during peak demand times called super red periods. These payments are made as this generation allows the DNO to defer the reinforcement or upgrade of their grid. To receive these credits generators must be connected to their DNO’s Extra High Voltage (EHV) grid and be a non-intermittent generator. These credits are only applicable to generators in specific areas where their generation defers grid reinforcement. Participation in Super Red Credits payments is possible for renewable sources with battery storage. It allows the provider to produce non-intermittent generation and time shift energy generated by renewables at other times of day into the super red period to maximise its commercial benefit. Participation is only possible when the service provider is connected to a specific part of the distribution grid, which is reinforced by their generation.
To enter a non-intermittent power purchase agreement (PPA) the generator must be able to generate at an agreed power level for an agreed time period. A non-intermittent PPA also means renewable energy generators can receive a variable energy rate instead of a fixed one, making it beneficial to generate at peak times when a higher rate is available. A non-intermittent PPA can be considered as a long-term revenue source for a renewable source with energy storage, but the uplift in revenue is likely to be low compared to other end uses.
In order to maximise a project’s commercial position, it is possible to “stack” revenue sources. Energy storage is proposed to add flexibility to the electrical grid. Typically there is limited uplift in value from storing energy purely for dispatch at times of higher prices, and so energy storage systems must gain maximum revenue through the provision of flexibility.
The ability to stack revenue streams, and the optimal stacking solution, will be site and developer dependent, considering: the availability of the grid connection, the type, specification and applicability to each end use of the energy storage system, and the appetite for risk in depending upon future revenue streams which have relatively short contract durations. On occasions, storage projects may choose to be penalised for non-compliance with the conditions of one source of revenue in order to benefit from the rewards offered under another regime.
Some revenue streams can be combined by tendering services at different times, with priority given to higher value services. Other services will require additional power or storage capacity, which increases capital costs. Therefore the business case for each revenue stream can be tested against additional capital and operating costs applicable to that service. Furthermore, offering an additional service may reduce revenue available from another service due to mismatch in the technical or contractual requirements between services.
Navigating the complex array of criteria for each revenue stream is challenging. As the cost of energy storage drops, the need for revenue stacking to ensure a project’s economic viability is likely to reduce.
